Running FreeBSD from NixOS using Libvirtd from scratch

How to run FreeBSD alongisde Nixos on the same computer for quick tests using libvirtd to stop having recompilation issues of VirtualBox

Running FreeBSD from NixOS using Libvirtd from scratch
Photo by Noyo creatif / Unsplash

I use FreeBSD for work because my clients deploy servers on it. At home, I have a PC with 32 GB of RAM and use NixOS, so I wanted to run FreeBSD locally for quick tests.

My first choice would normally be VirtualBox, but on NixOS it’s a pain: every system upgrade forces VirtualBox to be recompiled. Since I upgrade often, that became unmanageable.

People in the fediverse suggested libvirtd, so I gave it a try. It’s trickier at first, but once you learn a few commands it’s not bad at all—and in fact, it allows for a lot of automation.

Installing Libvirtd

In configuration.nix you need to make the following changes.

# Add the user to these groups, internet wisdom is not clear about what exactly is the name of each group.

users.users.maikel = {
  extraGroups = [ "libvirtd", "libvirt", "qemu-libvirtd" ];
};

# Enable libvirtd
virtualisation = {
  libvirtd = {
      enable = true;
      qemu.vhostUserPackages = with pkgs; [ virtiofsd ];
    };
};

# Add Virt-Manager makes simpler to explore actual configs.
programs.virt-manager.enable = true;


environment = {
  systemPackages = with pkgs; [
    virt-viewer
    cloud-utils
    cloud-init
    ];
};

Running commands when using Libvirtd as a system's service

Despite all the changes there, I still need to prepend all virsh and virt-viewer commands with

# For Virsh
virsh -c qemu:///system

# For Virt-viewer
virt-viewer -c qemu:///system

Either that or put sudo ahead of all virsh commands. Since I'm lazy I prefer to do what works every time and since I use Fish shell, I just added to ~/.config/fish/conf.d/abbreviations.fish

abbr --add virt-viewer "virt-viewer -c qemu:///system"
abbr --add virsh "virsh -c qemu:///system"

That way every time I write either it auto completes so assume every command below takes this into account. If you don't want to autocomplete either use sudo (for virsh) or the whole -c qemu:///system for virt-viewer (can't use sudo, you need the display). I like abbr instead of alias because with abbr I don't actually forget the full command ever. It's shown to me every time.

Configuring the Network

By default there's nothing running network wise. So you need to start the default network with

# Starts it if you can't see any new networks in ifconfig
virsh net-start default

# So it autostarts
virsh net-autostart default

That will run the virtual network every time the PC reboots.

Creating a cloud-init enabled image

💡
IMPORTANT

Always download the VM version, not the installer version from https://www.freebsd.org/where/

For standard VM image (UFS)

This will create a template on your PC to run cloud-init from the standard VM image that uses as filesystem UFS, if you need ZFS move onto the next step.

# Make a folder for your vms
mkdir ~/vms
cd ~/vms

# Download standard VM image and unzip it
wget https://download.freebsd.org/releases/VM-IMAGES/14.3-RELEASE/amd64/Latest/FreeBSD-14.3-RELEASE-amd64.qcow2.xz

# Decompress but keeps the original
xz -dk FreeBSD-14.3-RELEASE-amd64.qcow2.xz

# Make the disk slightly bigger
mv FreeBSD-14.3-RELEASE-amd64.qcow2 freebsd14-cloud-init.qcow2
qemu-img resize freebsd14-cloud-init.qcow2 10G

# Run it with the "default" network to install CloudInit
virt-install \
  --connect qemu:///system \
  --name freebsd14 \
  --memory 2048 \
  --vcpus 2 \
  --disk path=./freebsd14-cloud-init.qcow2,format=qcow2,bus=virtio \
  --os-variant freebsd14.0 \
  --import \
  --network network=default,model=virtio \
  --graphics spice

Now inside the machine

The default root user is passwordless so if you use "root" it won't ask for any password, just log you in.

# OPTIONAL: Keyboard to Spanish, symbols are in different places
kbdcontrol -l es

# Now inside the machine prepare it for cloud-init (as root, no pass)
pkg update
pkg search cloud-init
pkg install -y WHATEVER_VERSION_YOU_GOT_FROM_SEARCH

# Now enable it
sysrc cloudinit_enable="YES"
poweroff

# On your host system: Back it up
xz -k freebsd14-cloud-init.qcow2

For a ZFS VM image

This will create a template on your PC to run cloud-init from the ZFS VM image that uses as filesystem ZFS, the most common case.

# Make a folder for your vms
mkdir ~/vms
cd ~/vms

# Download standard VM image and unzip it
wget https://download.freebsd.org/releases/VM-IMAGES/14.3-RELEASE/amd64/Latest/FreeBSD-14.3-RELEASE-amd64-zfs.qcow2.xz

# Decompress but keeps the original
xz -dk FreeBSD-14.3-RELEASE-amd64-zfs.qcow2.xz

# Make the disk slightly bigger
mv FreeBSD-14.3-RELEASE-amd64-zfs.qcow2 freebsd14-cloud-init-zfs.qcow2
qemu-img resize freebsd14-cloud-init-zfs.qcow2 10G

# Run it with the "default" network to install CloudInit
virt-install \
  --connect qemu:///system \
  --name freebsd-zfs \
  --memory 2048 \
  --vcpus 2 \
  --disk path=./freebsd14-cloud-init-zfs.qcow2,format=qcow2,bus=virtio \
  --os-variant freebsd14.0 \
  --import \
  --network network=default,model=virtio \
  --graphics spice

Now inside the machine

The default root user is passwordless so if you use "root" it won't ask for any password, just log you in. This is pretty much the same as with UFS. Only changes the file you back up.

# OPTIONAL: Keyboard to Spanish, symbols are in different places
kbdcontrol -l es

# Now inside the machine prepare it for cloud-init (as root, no pass)
pkg update
pkg search cloud-init
pkg install -y WHATEVER_VERSION_YOU_GOT_FROM_SEARCH

# Now enable it
sysrc cloudinit_enable="YES"
poweroff

# On your host system: Back it up
xz -k freebsd14-cloud-init-zfs.qcow2

Using your own templates to launch custom-made VMs quickly

Create a cloud-init config

  1. Create this file as user-data.yaml on the ~/vms folder
#cloud-config
hostname: freebsd
users:
  - name: maikel
    shell: /usr/local/bin/fish
    sudo: ALL=(ALL) NOPASSWD:ALL
    lock_passwd: false
    # Use mkpasswd to get this
    passwd: "$6$L80IKTw......dbZewtsw5FjosH0"
    # Your public key for SSH
    ssh_authorized_keys:
      - ssh-ed25519 AAAAC3NzaC1.... ...@maikel.dev
ssh_pwauth: True
keyboard:
  layout: es
# Any packages you need in FreeBSD go here
packages:
  - fish
  - sudo
  - mkpasswd
  - neovim
  - git
runcmd:
  # Enable SSH
  - sysrc sshd_enable=YES
  - service sshd start
  # Set Spanish keyboard permanently
  - sysrc keymap="es.kbd"
  - service syscons restart
  # Optional: set root and maikel shells to fish explicitly
  - pw usermod root -s /usr/local/bin/fish
  - pw usermod maikel -s /usr/local/bin/fish
  1. Use this command to create a CD-ROM ISO to launch it from. Assuming you're in ~/vms
cloud-localds seed.iso user-data.yaml

Creating the final machine using the ZFS image

The instructions are prety much the same for a UFS image you just change the filenames.

# Access the folder of your vms
cd ~/vms

# Decompress the fresh cloud-init-enabled version we created before.
xz -dk freebsd14-cloud-init-zfs.qcow2.xz

# Rename it to something more useful to distinguish it from the template
cp freebsd14-cloud-init-zfs.qcow2 freebsd14-ready.qcow2

# Create the seed ISO from user-data.yaml in case you've made any changes.
cloud-localds seed.iso user-data.yaml

# Make the disk bigger here it is set to 20G but you can do whatever size you like
qemu-img resize freebsd14-ready.qcow2 20G

# Install
virt-install \
  --connect qemu:///system \
  --name freebsd-new \
  --memory 2048 \
  --vcpus 4 \
  --disk path=freebsd14-ready.qcow2,format=qcow2,bus=virtio \
  --disk path=seed.iso,device=cdrom \
  --os-variant freebsd14.0 \
  --import \
  --network network=default,model=virtio \
  --graphics spice \
  --noautoconsole # Added this here because I prefer to let it run first.

# To view
virt-viewer freebsd-new

And that's it, your system should be up and running ready to be used. 🥳

My Lenovo P510 running Nixos and FreeBSD

Extra steps for your own sanity

Resizing the partition to use all available space (ZFS)

If you want your system to use all the available space in your qcow2 file after resizing it you'll need some extra steps.

# Ensure vtbd0 is the name of it
gpart show

# Reize partition
gpart recover vtbd0

# Get the lice or number of partition, in my case is 4
gpart show

# This is assumign the slice is 4
gpart resize -i 4 vtbd0

# Again the end "p4" depends on the slice number
zpool online -e zroot /dev/vtbd0p4

That's all your machine is ready to use. If you ever need to change the size of the qcow2 file repeat those steps.

Autostart this machine with NixOS with Nixos

Run on the host machine

virsh --connect qemu:///system autostart freebsd-new

Detach cloud-init disk just in case

Normally cloud-init runs only once, but just to be sure on the host machine

# To find the name of the ISO device, in my case "hda"
sudo virsh domblklist freebsd-new

# To both remove it and ensure it never comes back after reboot
virsh --connect qemu:///system change-media freebsd-new hda --eject --config --live

SSH-ing in made easier with Fish shell functions

I don't want to have to finding the IP before I connect so I wrote this fish shell function stored in ~/.config/fish/functions/sshvm which uses the global variable $LOCAL_VM_KEY as path to the private key used to log into the FreeBSD VM. I defined that key in ~/.config/fish/conf.d/variables

function sshvm
	# This gets the IP of the server with the given name
    set ip (virsh --connect qemu:///system domifaddr $argv[1] | string match -r '\d+\.\d+\.\d+\.\d+' | head -n1)
    # This connects to the server using the private key
    ssh -i $LOCAL_VM_KEY maikel@$ip
end

Then I just use

sshvm freebsd-new

Or whatever name I gave to that virtual machine.

Cleaning up

# See the machines
sudo virsh list --all

# The first stops immediately the machine
sudo virsh destroy freebsd14

# This second removes it from the pool of VMs of libvirtd
sudo virsh undefine frebsd14

# Delete any pre-made seed just in case
rm -rf seed.iso

Some oddities

These are some painful parts from the process.

The command Virt-install and "~"

I don't know why the path can't interpret "~" hence why I did it all from the ~/vms folder

Run without virt-viewer

Sometimes you want to install and see nothing, in those case use

  --graphics spice \
  --noautoconsole

At the end of the virt-install command, this runs the system with graphics enable but doesn't attach any viewer to it.
